Started my D2 install... need a pointer or 2


  • Please log in to reply
12 replies to this topic

#1 tg118

tg118

    Member

  • Members
  • PipPip
  • 381 posts
  • Gender:Male
  • Location:PA
  • Interests:Moto-x , Conquest
  • Model:Conquest

Posted 13 March 2012 - 10:23 AM

Ok , so i started my D2 install yesterday... i started on the rear ones have everything unbolted, but the bottom of the assembly doesnt want to come out of the mount, im sure because of the years of rusting together ,,, any tips to getting it out of there? and will i need to compress the spring to get it out of there?
Posted Image Posted Image Posted Image





#2 dmyers151

dmyers151

    Go-Kart Mozart

  • Members
  • PipPipPipPip
  • 7,163 posts
  • Gender:Male
  • Location:Monroe, NY
  • Interests:Toys & Candy
  • Model:Conquest

Posted 13 March 2012 - 10:38 AM

You gotta pull the thru bolt all the way out. The bottom of the strut housing has a groove in it where the bolt passes through.

I don't think you'll need a spring compressor. Just unbolt the sway bar and axles and drop the control arm down.

#3 tg118

tg118

    Member

  • Members
  • PipPip
  • 381 posts
  • Gender:Male
  • Location:PA
  • Interests:Moto-x , Conquest
  • Model:Conquest

Posted 13 March 2012 - 10:43 AM

View Postdmyers151, on 13 March 2012 - 10:38 AM, said:

You gotta pull the thru bolt all the way out. The bottom of the strut housing has a groove in it where the bolt passes through.

I don't think you'll need a spring compressor. Just unbolt the sway bar and axles and drop the control arm down.
that Thru bolt really dont want to come out,, the Nut came off easy...Bigger hammer ?
Posted Image Posted Image Posted Image

#4 dmyers151

dmyers151

    Go-Kart Mozart

  • Members
  • PipPipPipPip
  • 7,163 posts
  • Gender:Male
  • Location:Monroe, NY
  • Interests:Toys & Candy
  • Model:Conquest

Posted 13 March 2012 - 10:46 AM

Yeah, soak it in blaster/wd40/whatever and let it sit a while. Then go in with a hammer & punch or air chisel.

#5 19cturbo

19cturbo

    BREAKFAST OF CHAMPIONS! BOOST!

  • Members
  • PipPipPipPip
  • 6,386 posts
  • Gender:Male
  • Location:KINGSPORT TN.
  • Interests:cars
  • Model:Starion

Posted 13 March 2012 - 10:58 AM

put the nut on the end of the bolt so you dont damage it, then try twisting the bolt with a wrench and tapping the nut end with a hammer.. apply PB blaster, in large amounts.. clean the bolt good before it goes back in.. once you get it out the strut should come out pretty easy. if it doesnt you may have to take a chisel and spread the pinch joint a little.
Being not real since I learned what was good for me
Posted Image

#6 tg118

tg118

    Member

  • Members
  • PipPip
  • 381 posts
  • Gender:Male
  • Location:PA
  • Interests:Moto-x , Conquest
  • Model:Conquest

Posted 13 March 2012 - 12:18 PM

I will try that tonight, stocked up on PB balst, guess i just gotta have a lil patience, ill let ya know how it goes... thanks
Posted Image Posted Image Posted Image

#7 Technology

Technology

    TheNerdyProfessor

  • Members
  • PipPipPipPipPip
  • 11,246 posts
  • Gender:Male
  • Location:China
  • Interests:Lots of boost!
  • Model:Other

Posted 13 March 2012 - 12:32 PM

you may need an air hammer for that one bolt. I've twisted one off before, that's no fun.

Posted Image


#8 JohnnyWadd

JohnnyWadd

    Advanced Member

  • Vendors
  • PipPipPipPip
  • 7,870 posts
  • Gender:Male
  • Location:Oregon
  • Model:Conquest

Posted 13 March 2012 - 12:36 PM

The before mentioned hammer tapping is the way to go , hit it anyhere you can that wont damage it,like on the hub carrier too, that will fracture the rusted togetherness off it, especially if you have an air hammer. Even a few good smacks on the bolt head(may need long chisel) like your driving a nail, i know that sounds wrong like you want it to move the other way but it will crack the rust seal so to speak.

#9 tg118

tg118

    Member

  • Members
  • PipPip
  • 381 posts
  • Gender:Male
  • Location:PA
  • Interests:Moto-x , Conquest
  • Model:Conquest

Posted 13 March 2012 - 12:59 PM

ive been beating on it , being careful not to damage the bolt,soaked again last after i gave in, so im hoping i can get it later.... is that thru bolt special, is there a replacment?
Posted Image Posted Image Posted Image

#10 19cturbo

19cturbo

    BREAKFAST OF CHAMPIONS! BOOST!

  • Members
  • PipPipPipPip
  • 6,386 posts
  • Gender:Male
  • Location:KINGSPORT TN.
  • Interests:cars
  • Model:Starion

Posted 13 March 2012 - 01:03 PM

Will the bolt turn?
Being not real since I learned what was good for me
Posted Image

#11 tg118

tg118

    Member

  • Members
  • PipPip
  • 381 posts
  • Gender:Male
  • Location:PA
  • Interests:Moto-x , Conquest
  • Model:Conquest

Posted 13 March 2012 - 01:09 PM

View Post19cturbo, on 13 March 2012 - 01:03 PM, said:

Will the bolt turn?
No the bolt wont Turn, i put quite a bit of pressure on it, but was afraid of snapping it, the nut came off fine
Posted Image Posted Image Posted Image

#12 Killtodie

Killtodie

    KTD

  • Members
  • -219,400 posts
  • Gender:Male
  • Location:Chicago, IL
  • Model:Conquest

Posted 13 March 2012 - 03:15 PM

blast it with PB Blaster all around, get the bolt to rotate. You might wanna try taking some channel locks and a large flat head screw driver and try to separate that gap and use channel locks to close it. Get more PB Blaster in there and tap at the bolt to get it loose.

Not a special bolt, I think Mitsu still carries it. NudeLobster had issues with it and he bought new ones.
Posted Image
My Repair Progress Post!

View PostBag-O-Chips, on 13 September 2011 - 09:36 PM, said:

Toadie... not all of us scrape bubble gum off pavement :)

#13 tg118

tg118

    Member

  • Members
  • PipPip
  • 381 posts
  • Gender:Male
  • Location:PA
  • Interests:Moto-x , Conquest
  • Model:Conquest

Posted 13 March 2012 - 08:44 PM

lots o PB Blast + turning the Bolt bit by bit+ screwdriver as a wedge & an asssload of patience got it off,,, thanks for the tips 1 down 3 to go !

what is the best way to set the d2's for a starting point, close to normal height, or a bit lower, i kinda know how i want her to sit, just want the best staring point
Posted Image Posted Image Posted Image
