Fuel Line Length


  • Please log in to reply
10 replies to this topic

#1 bthotrod

bthotrod

    Member

  • Members
  • PipPipPip
  • 111 posts
  • Gender:Male
  • Location:Smithfield, NC
  • Model:Other

Posted 02 March 2018 - 09:57 PM

Anyone know about how long the fuel lines are from the tank up to the back of the motor? Looking to upgrade to -8AN feed and return lines on my V8 Quest, and don't know how much to order.
Would 33 feet (10m) work? I'd assume so..

Thanks!
1988 Chrysler Conquest V8 302 Swap

- Rear 8s with 225/50 and 245/50 tires
- Ford 302 with XE262H-10 Cam, ported heads, performer RPM intake





#2 croquest87

croquest87

    Established Member

  • Members
  • PipPipPip
  • 1,836 posts
  • Gender:Male
  • Location:willoughby
  • Interests:all things mechanical
  • Model:Conquest

Posted 03 March 2018 - 04:26 PM

Should be ok.   but measuring tape does wonders

#3 Chad

Chad

    noob

  • Moderators
  • PipPipPipPip
  • 9,182 posts
  • Gender:Male
  • Location:Lincoln City Oregon
  • Interests:Starquest Fanatic
  • Model:Conquest

Posted 03 March 2018 - 09:50 PM

its about 15', depending on how you route it.  the whole car is under 17'.

#4 bthotrod

bthotrod

    Member

  • Members
  • PipPipPip
  • 111 posts
  • Gender:Male
  • Location:Smithfield, NC
  • Model:Other

Posted 04 March 2018 - 10:58 PM

View Postcroquest87, on 03 March 2018 - 04:26 PM, said:

Should be ok.   but measuring tape does wonders

Car was at shop, needed to order over the weekend so they could be here asap. Not trying to be lazy here... plus the info could be useful to someone else who may want to do so.

View PostChad, on 03 March 2018 - 09:50 PM, said:

its about 15', depending on how you route it.  the whole car is under 17'.

Thank you! Hopefully this will be enough. I'll update the thread once I run all the lines and say how much it took.
1988 Chrysler Conquest V8 302 Swap

- Rear 8s with 225/50 and 245/50 tires
- Ford 302 with XE262H-10 Cam, ported heads, performer RPM intake

#5 techboy

techboy

    Established Member

  • Members
  • PipPipPip
  • 3,840 posts
  • Gender:Male
  • Location:Lehigh Valley, PA
  • Interests:80's & 90's turbo charged cars.
  • Model:Starion

Posted 04 March 2018 - 11:44 PM

You're still gonna run a hard line under the car, right?  I know you can run a soft line the length of the car from tank to TB, (heck, I did it myself many years ago on another car) - but it's not particularly safe.  Food for thought.
1988 Starion ESi-R ... crushed by a tree 10/31/11 - back from the dead 8/2016
1988 Conquest TSi ... current driver - sold to Bigjoe 6/2016
1987 Conquest Flatty ... F/S thread - sold 8/2014
1987 Conquest TSi ... parts car - sold to Coldscrip 12/2011
1999 Eclipse 4G63 ... heavily modified.
Feeback Thread | Motor rebuild thread | Restoration thread

Posted Image

#6 bthotrod

bthotrod

    Member

  • Members
  • PipPipPip
  • 111 posts
  • Gender:Male
  • Location:Smithfield, NC
  • Model:Other

Posted 10 March 2018 - 11:26 PM

View Posttechboy, on 04 March 2018 - 11:44 PM, said:

You're still gonna run a hard line under the car, right?  I know you can run a soft line the length of the car from tank to TB, (heck, I did it myself many years ago on another car) - but it's not particularly safe.  Food for thought.

No, no hardline for this car for now. It's safer to run hardline usually, but this is going to be carefully routed metal braided CPE line - not some rubber hose ziptied up lol. Still probably not ideal, but as long as it's kept away from anything that moves and above the "frame rails" then I'm sure it'll be fine in the long run.

NHRA actually states that all non-OEM fuel lines can be either metallic hardline, OR steel braided. I'm not trying to drag race this car, but usually if a racing organization allows it then it's pretty safe.
1988 Chrysler Conquest V8 302 Swap

- Rear 8s with 225/50 and 245/50 tires
- Ford 302 with XE262H-10 Cam, ported heads, performer RPM intake

#7 techboy

techboy

    Established Member

  • Members
  • PipPipPip
  • 3,840 posts
  • Gender:Male
  • Location:Lehigh Valley, PA
  • Interests:80's & 90's turbo charged cars.
  • Model:Starion

Posted 12 March 2018 - 10:52 AM

View Postbthotrod, on 10 March 2018 - 11:26 PM, said:


NHRA actually states that all non-OEM fuel lines can be either metallic hardline, OR steel braided. I'm not trying to drag race this car, but usually if a racing organization allows it then it's pretty safe.

Good point.
1988 Starion ESi-R ... crushed by a tree 10/31/11 - back from the dead 8/2016
1988 Conquest TSi ... current driver - sold to Bigjoe 6/2016
1987 Conquest Flatty ... F/S thread - sold 8/2014
1987 Conquest TSi ... parts car - sold to Coldscrip 12/2011
1999 Eclipse 4G63 ... heavily modified.
Feeback Thread | Motor rebuild thread | Restoration thread

Posted Image

#8 gst4g64

gst4g64

    Member

  • Members
  • PipPipPip
  • 407 posts
  • Gender:Male
  • Location:Pittsburgh, PA
  • Model:Conquest

Posted 12 March 2018 - 06:55 PM

I did an -8AN feed and -6AN return in braided line and had to run hardlines for inspection (penndot).

#9 jcstarion88

jcstarion88

    Member

  • Members
  • PipPipPip
  • 218 posts
  • Gender:Male
  • Location:Moultrie Ga
  • Interests:cars bikes computers
  • Model:Starion

Posted 19 February 2021 - 12:23 PM

@gst4g64 what brand name for the lines?
😎
My 1988 Starion
Posted Image
Check out all My Pics @ http://s1007.photobu...3/jcskaterdude/
1g MAF, Trilogy Turbos hood struts, 1 piece Airdam with stainless steel brackets, CT26 turbo setup, KDM 2.5" aluminum pipes, cusco front strut bar, more to come!>
A POST WITH NO PICS IS NOTHING...

#10 importwarrior

importwarrior

    6 Quests and Counting......

  • Moderators
  • PipPipPipPipPip
  • 18,407 posts
  • Gender:Male
  • Location:Manassas VA
  • Interests:Boost = 2KWIK4U
    Starquests
  • Model:Conquest

Posted 19 February 2021 - 01:43 PM

i would use hard lines for sure but
if you use hose use PTFE hose with proper PTFE Fittings.


but this is a good source

Home page | AN Plumbing

B-71 87 TSI ~ RIP

Black 87 Starion ~ Mess SOLD!!!

Proud New 89 slightly Rusted Fiji Owner !!!




#11 kev

kev

    Moderator

  • Moderators
  • PipPipPipPip
  • 5,282 posts
  • Gender:Male
  • Location:PA
  • Model:Other

Posted 23 February 2021 - 05:04 PM

I sent my originals to inlinetube and they custom bent me new stainless steel lines with AN fittings.   I went with -8 and -6AN for the supply and return, respectfully.   I don't remember the exact price for I also had all of my brake lines done at the same time.   But it was a fast turnaround.
