WHERE IS THE FUEL PUMP RELAY?!?!?!?


  • Please log in to reply
15 replies to this topic

#1 patra_is_here

patra_is_here

    Advanced Member

  • Members
  • PipPipPipPip
  • 8,358 posts
  • Gender:Male
  • Location:monterey ca
  • Interests:86 starion
  • Model:Other

Posted 02 January 2008 - 07:07 PM

86 esir

i'm looking in the service manual right now, but, in case i can't find it, someone where might know.





#2 UlrichWolf

UlrichWolf

    Mayhem....it's WHAT I DO

  • Members
  • PipPipPipPip
  • 7,087 posts
  • Gender:Male
  • Location:Wichita, KS
  • Model:Other

Posted 02 January 2008 - 07:15 PM

Technically, there isn't one.

However, I believe what might point you in the correct direction, is the "main relay" located above the ECU.

Tim
Posted Image

Oh what a tangled web we weave, when first we practice to deceive.


#3 patra_is_here

patra_is_here

    Advanced Member

  • Members
  • PipPipPipPip
  • 8,358 posts
  • Gender:Male
  • Location:monterey ca
  • Interests:86 starion
  • Model:Other

Posted 02 January 2008 - 07:21 PM

well, looking at the wiring diagram, there's definitely some sort of relay in line with the fuel pump. is the main relay a large relay, with say, maybe 8 wires?

#4 UlrichWolf

UlrichWolf

    Mayhem....it's WHAT I DO

  • Members
  • PipPipPipPip
  • 7,087 posts
  • Gender:Male
  • Location:Wichita, KS
  • Model:Other

Posted 02 January 2008 - 07:23 PM

Yeah, it's got a lot of connections on it.

Tim
Posted Image

Oh what a tangled web we weave, when first we practice to deceive.


#5 patra_is_here

patra_is_here

    Advanced Member

  • Members
  • PipPipPipPip
  • 8,358 posts
  • Gender:Male
  • Location:monterey ca
  • Interests:86 starion
  • Model:Other

Posted 02 January 2008 - 07:36 PM

thanks homie!

#6 Truth

Truth

    Incredibly Sexy Member

  • Members
  • PipPipPipPip
  • 9,319 posts
  • Gender:Male
  • Location:Charlotte, North Carolina
  • Interests:Cars, Women, Music, Food
  • Model:Conquest

Posted 02 January 2008 - 08:53 PM

i thought the fuel pump relay was the two-wired relay near the 5 a/c relays on the bracket above the coil?
-A.J.
2004 Honda S2000

#7 Dad

Dad

    Advanced Member

  • Vendors
  • PipPipPipPip
  • 8,089 posts
  • Gender:Male
  • Location:Niles,Ohio
  • Interests:One stock and one not!
    87 White Quest
    87 Shetland
    83 Starion- Chevy powered
    ___________________________
  • Model:Conquest

Posted 02 January 2008 - 08:55 PM

Just above the ECU


If I'm right  do I get a prize?

Dad

#8 JAinsworth

JAinsworth

  • Moderators
  • PipPipPipPipPip
  • 16,871 posts
  • Gender:Male
  • Location:Lizella Georgia
  • Model:Conquest

Posted 02 January 2008 - 09:04 PM

QUOTE (Dad)
Just above the ECU


If I'm right  do I get a prize?

Dad


Not from me biggrin.gif   But I will agree with your answer.....but...are you smarter than a 5th grader :shock:

Jimmy

#9 indy_85stariones

indy_85stariones

    Established Member

  • Members
  • PipPipPip
  • 3,639 posts
  • Location:IN, Indianapolis
  • Interests:Keep her running just one more day!
  • Model:Starion

Posted 02 January 2008 - 10:29 PM

QUOTE (UlrichWolf)
Technically, there isn't one.

However, I believe what might point you in the correct direction, is the "main relay" located above the ECU.

Tim


The "main relay" has two circuits...
1)  one to provide power for injectors
2)  the other, to provide power to fuel pump
(note - unlike most japanese 80's cars, our "relay" doesn't provide power to the fuel pump when key is in "ON" position.  It waits until key is in "START" position before providing power to fuel pump.  Usually our cars won't start on the first cranking attempt, because it takes some time for our fuel pressure to build up.)




#10 randomguy

randomguy

    most anti-SQer alive

  • Members
  • PipPipPip
  • 1,617 posts
  • Gender:Male
  • Location:⎝⏠⏝⏠⎠
  • Interests:$
  • Model:Starion

Posted 03 January 2008 - 02:07 AM

orly on my FIP i hooked it up to the golden thing behind/under the glove compartment (what i thought was the fuel pump relay lol)

it worked lol
Posted Image

#11 Indiana

Indiana

    Addicted Starquester

  • Members
  • PipPipPipPipPip
  • 14,730 posts
  • Gender:Male
  • Location:Bloomington, IN
  • Model:Other

Posted 03 January 2008 - 02:26 AM

the fuel pump relay is half of the control relay







BW-black/white stripe   01 / (+) output / turns on the Fuel Pump when starter is cranking or engine is running

WR-white/red stripe     02 / (-)  input / signal from ECU to activate fuel pump relay after

                                              ign. switch moves from "start" position and engine is running

BR-black/red stripe      03 / (+) output / when ignition "on", this sends power to the injectors

B  -black                     04 / (-)  grounded to body

BY-black/yellow stripe   06 / (+) input / from ign. switch "start" position

                                              this activates a relay that turns on the fuel pump

R  -red                        05 / (+) output / when ignition "on", this powers the ECU

L  -blue                       08 / (+) input / from ign. switch "on" position

                                              this activates a relay that powers the ECU and the injectors

B  -black                     07 / (+) input / fuse link back to Battery positive terminal

#12 patra_is_here

patra_is_here

    Advanced Member

  • Members
  • PipPipPipPip
  • 8,358 posts
  • Gender:Male
  • Location:monterey ca
  • Interests:86 starion
  • Model:Other

Posted 03 January 2008 - 11:38 AM

thanks indiana! my wiring diagram had different colored wires listed, so, that pic really helped clarify.

#13 chasm2530

chasm2530

    Advanced Custom Member

  • Members
  • PipPipPip
  • 902 posts
  • Gender:Male
  • Location:South Birmingham, Alabama
  • Interests:Hot-Rod Sport Cars
  • Model:Conquest

Posted 03 January 2008 - 01:49 PM

QUOTE (JAinsworth)
QUOTE (Dad)
Just above the ECU


If I'm right  do I get a prize?

Dad


Not from me biggrin.gif   But I will agree with your answer.....but...are you smarter than a 5th grader :shock:

Jimmy

I won a million dollars on the "Are You Smarter Than a 5th Grader" home version...where's my check?
Posted Image

#14 DJpowerHaus

DJpowerHaus

    Established Member

  • Members
  • PipPipPip
  • 2,393 posts
  • Gender:Male
  • Location:Baltimore, MD
  • Interests:If that has a Spoon engine, mine's got a Shovel.
  • Model:Starion

Posted 03 January 2008 - 04:41 PM

Nice post!  I always wanted to know what was inside of that Main Relay.

:: Project 0G ::
www.ProjectZeroG.com

#15 Force_Feed1988

Force_Feed1988

    Established Member

  • Members
  • PipPipPip
  • 860 posts
  • Gender:Male
  • Location:Baton Rouge, LA
  • Model:Conquest

Posted 03 January 2008 - 04:47 PM

That relay right there caused about 2 days of heart ace for me. I unplugged it when changing the ECU, and the relay got pushed under the seat. For 2 Days I tried to get my car to run. I was getting no Spark or Fuel! After switching between ECU's dozens of times I realized There was something missing. After I found it, I Plugged that bad boy in and it started right up.

#16 dj_justice

dj_justice

    Member

  • Members
  • PipPip
  • 51 posts
  • Location:Rockville MD
  • Model:Other

Posted 18 April 2008 - 01:38 PM

QUOTE (Force_Feed1988 @ Jan 3 2008, 05:47 PM) <{POST_SNAPBACK}>
That relay right there caused about 2 days of heart ace for me. I unplugged it when changing the ECU, and the relay got pushed under the seat. For 2 Days I tried to get my car to run. I was getting no Spark or Fuel! After switching between ECU's dozens of times I realized There was something missing. After I found it, I Plugged that bad boy in and it started right up.


Im having a problem with my new fuel pump cutting out then coming back on then cutting out again. Could the relay be the culprit?
87 Broke Conquest TSI - Soon to be DD

85 Monte Carlo SS LT1 Powered - Weekend racer
